Image MCQ: CT Abdomen Acute Conditions for NEET PG (Appendicitis, Perforation, SBO, Pancreatitis, Aortic Dissection)

Version 1.0 — Published April 2026

Why CT abdomen image MCQs are high-yield in NEET PG

NEET PG radiology contributes 8-12 questions, with 50-60 percent being image-based. Of those, 3-5 questions reliably feature CT abdomen — appendicitis, perforation, obstruction, pancreatitis, and vascular emergencies are the perennial favourites. Unlike text questions, CT images reward pattern recognition: a 5-second glance gives the diagnosis if you have practiced the search pattern. The five MCQs below cover almost every recent NEET PG abdominal CT question (2019-2024 papers).

For each, we walk through the image description, the four answer options, the correct answer with reasoning, and a teaching pearl. Pair this with a daily 10-image CT habit for 2 weeks and your CT abdomen accuracy will jump from 40 to 85 percent.

MCQ 1: 24-year-old man with right iliac fossa pain and fever

Image description: [Axial contrast-enhanced CT of the abdomen at the level of the cecum. A blind-ending tubular structure arises from the cecal pole, measuring 11 mm in transverse diameter (normal <6 mm). The wall is thickened (3 mm) with mural enhancement. Surrounding mesenteric fat shows hazy increased density (fat stranding). A 4 mm calcified focus is visible within the lumen near the base. No free air; small amount of free fluid in the pelvis.]

Clinical vignette: A 24-year-old male presents to the surgical emergency with 18 hours of periumbilical pain that has migrated to the right iliac fossa, anorexia, vomiting once, low-grade fever 38.2 C. McBurney point tenderness, Rovsing positive, WBC 14,800, neutrophil predominance.

Options:

• (a) Acute mesenteric ischemia
• (b) Acute appendicitis
• (c) Crohn ileitis
• (d) Cecal diverticulitis

Correct answer: (b) Acute appendicitis

Reasoning: Six diagnostic CT findings of appendicitis — (1) dilated appendix >6 mm transverse diameter (here 11 mm); (2) wall thickening >2 mm with mural enhancement; (3) periappendiceal fat stranding; (4) appendicolith (visible in 30-40 percent); (5) focal cecal apical thickening (arrowhead sign); (6) periappendiceal fluid. Mesenteric ischemia shows pneumatosis intestinalis or portal venous gas in advanced cases, with bowel-wall thickening. Crohn ileitis shows long-segment ileal thickening with mesenteric creeping fat and skip lesions. Cecal diverticulitis is rarer and shows inflamed cecal diverticula with adjacent stranding, no appendiceal involvement.

Teaching pearl: Imaging algorithm for suspected appendicitis:

Treatment: uncomplicated appendicitis = laparoscopic appendectomy within 24 hours; complicated (abscess, phlegmon, perforation) = consider antibiotics first plus interval appendectomy at 6-8 weeks. Antibiotics-only therapy (CODA trial) is an option in selected uncomplicated adults, but recurrence rate is 25-40 percent at 1 year.

MCQ 2: 58-year-old man with sudden severe abdominal pain post-NSAID use

Image description: [Axial CT abdomen on lung-window settings. A large crescent of black gas density is visible anterior to the liver, conforming to the abdominal wall (subdiaphragmatic free air). Bowel loops show normal calibre. A small amount of fluid is seen in Morison pouch. On coronal reformat, gas is seen tracking along the falciform ligament. Stomach and duodenum demonstrate wall thickening with adjacent fat stranding around the duodenal bulb.]

Clinical vignette: A 58-year-old man with chronic knee pain on long-term diclofenac presents with sudden severe upper abdominal pain 6 hours ago that has now spread across the abdomen. He is in distress, BP 100/64, pulse 120. Abdomen is rigid with rebound tenderness. WBC 18,200.

Options:

• (a) Acute pancreatitis
• (b) Mesenteric ischemia
• (c) Perforated peptic ulcer
• (d) Splenic infarct

Correct answer: (c) Perforated peptic ulcer

Reasoning: The presence of free intraperitoneal air with adjacent inflammatory changes around the duodenum points to a perforated duodenal ulcer (NSAID-related, the most common cause in this age group). On CT, look for: free air anterior to liver on supine images (the "supine equivalent" of the upright CXR sign), Rigler sign (gas on both sides of bowel wall), falciform ligament outlined by air, and gas in the lesser sac. CT detects as little as 1-2 mL of free gas — 50 times more sensitive than upright CXR. Pancreatitis shows pancreatic enlargement and peripancreatic fluid without free air. Mesenteric ischemia shows bowel-wall thickening, pneumatosis intestinalis, or portal venous gas (not free intraperitoneal gas). Splenic infarct shows a wedge-shaped hypoperfused area in the spleen.

Teaching pearl: Lung-window settings (window width ~1500, level ~-600) are essential for detecting small amounts of free air. On soft-tissue windows, free air can be obscured by adjacent bowel gas. The classic mnemonic for free air on CT is "FACR":

• Falciform ligament outlined
• Anterior to liver
• Coronal reformat — subdiaphragmatic
• Rigler sign — both sides of bowel wall

Management of perforated peptic ulcer: aggressive resuscitation, IV PPI (pantoprazole 80 mg bolus then 8 mg/hr), broad-spectrum antibiotics (covering gram-negative and anaerobes — piperacillin-tazobactam or ceftriaxone + metronidazole), urgent laparotomy with Graham omental patch repair plus peritoneal lavage. Conservative management (Taylor regimen) is reserved for patients unfit for surgery.

MCQ 3: 64-year-old woman with bilious vomiting 3 years post-hysterectomy

Image description: [Axial CT abdomen showing multiple dilated small bowel loops (4-5 cm in calibre, normal <2.5 cm) in the central abdomen with multiple air-fluid levels. The dilated loops extend to a focal point in the right lower quadrant where there is an abrupt transition to collapsed distal small bowel. No mass is seen at the transition point. Mesenteric vessels appear normal. Small amount of free fluid in the pelvis. The colon is collapsed.]

Clinical vignette: A 64-year-old woman with prior abdominal hysterectomy 3 years ago presents with 24 hours of colicky abdominal pain, distension, multiple episodes of bilious vomiting, and obstipation. Abdomen is distended with hyperactive tinkling bowel sounds. BP 130/80, pulse 96.

Options:

• (a) Adhesive small bowel obstruction
• (b) Closed-loop obstruction with strangulation
• (c) Gallstone ileus
• (d) Sigmoid volvulus

Correct answer: (a) Adhesive small bowel obstruction

Reasoning: Three CT criteria for SBO — (1) dilated small bowel >2.5 cm in calibre, (2) air-fluid levels, (3) collapsed distal bowel with a transition point. The transition point with no mass and prior surgery makes adhesions the most likely cause (responsible for 60-70 percent of SBO in adults with prior surgery). Closed-loop obstruction shows two transition points close together with a C-shaped or U-shaped distended loop and signs of strangulation (bowel-wall thickening, mural pneumatosis, mesenteric edema, decreased mural enhancement, "swirl sign" of mesenteric vessels) — surgical emergency. Gallstone ileus shows the Rigler triad (pneumobilia + SBO + ectopic gallstone in bowel) — most commonly the gallstone lodges at the terminal ileum. Sigmoid volvulus shows a "coffee-bean" or "inverted U" distended sigmoid loop with a whirl sign at the base.

Teaching pearl: The "search ladder" for SBO etiology on CT:

1. Trace the dilated loops downstream until they meet collapsed bowel — that is the transition point
2. Look at the transition point — mass? hernia (defect in abdominal wall)? volvulus (whirl)? gallstone? closed loop?
3. No identifiable cause + prior surgery = adhesion (a diagnosis of exclusion)
4. Look for strangulation signs — wall thickening, pneumatosis, mesenteric edema, decreased enhancement, free fluid out of proportion to obstruction

Management: 90 percent of adhesive SBO without strangulation resolves with conservative management — NG decompression, IV fluids, electrolyte correction, gastrografin challenge (oral water-soluble contrast both diagnostic and therapeutic — passage of contrast to colon within 24 hours predicts non-operative resolution). Surgery if strangulation suspected, closed-loop, complete obstruction not resolving in 48-72 hours, or peritonitis.

MCQ 4: 48-year-old alcoholic man with severe epigastric pain radiating to back

Image description: [Axial contrast-enhanced CT abdomen at the level of the pancreas. The pancreas is diffusely enlarged with heterogeneous enhancement. There is loss of normal lobulation. Multiple peripancreatic fluid collections are seen — one in the lesser sac (3 cm), another along the left anterior pararenal space (4 cm). A non-enhancing area occupies approximately 40 percent of the pancreatic body and tail (necrosis). Peripancreatic fat stranding is extensive. No gas in the necrotic area. No free intraperitoneal air.]

Clinical vignette: A 48-year-old alcoholic man presents with 36 hours of severe epigastric pain radiating to the back, persistent vomiting. BP 100/68, pulse 116, SpO2 92 percent on room air. Lipase 1,840 U/L (normal <60), amylase 980 U/L. CRP 248 mg/L. Calcium 7.6 mg/dL.

Options:

• (a) Mild interstitial edematous pancreatitis (Balthazar B)
• (b) Severe necrotising pancreatitis (Balthazar E with 30-50 percent necrosis)
• (c) Chronic pancreatitis with calcifications
• (d) Pancreatic adenocarcinoma

Correct answer: (b) Severe necrotising pancreatitis (Balthazar E with 30-50 percent necrosis)

Reasoning: Balthazar grading system (original, 1985):

This patient has multiple fluid collections and ~40 percent necrosis — Balthazar E with significant necrosis.

Modified CT Severity Index (MCTSI, total score 0-10):

This patient: D-E (4) + 30-50% necrosis (4) + extrapancreatic (2) = MCTSI 10 — severe, with mortality risk of 50-70 percent.

Severity stratification: 0-2 mild, 4-6 moderate, 8-10 severe. Atlanta classification (revised 2012) categorises pancreatitis as: interstitial edematous (most common, mild) or necrotising (sterile vs infected). Acute peripancreatic fluid collection (APFC) within 4 weeks; pseudocyst after 4 weeks (encapsulated). Acute necrotic collection (ANC) within 4 weeks; walled-off necrosis (WON) after 4 weeks.

Teaching pearl: Best timing for CT in pancreatitis is 72-96 hours after symptom onset — earlier scans underestimate necrosis. CT in the first 24-48 hours is reasonable only when diagnosis is uncertain. Use IV contrast unless eGFR <30 — necrosis is identified as a non-enhancing area. Repeat CT at 7-10 days if clinical deterioration to assess for infected necrosis (gas in collection is pathognomonic for infection).

Management of severe pancreatitis: ICU admission, aggressive IV crystalloid resuscitation (Lactated Ringer 5-10 mL/kg/hr titrated to urine output >0.5 mL/kg/hr), early enteral nutrition (NJ tube within 72 hours — better than TPN), no prophylactic antibiotics (only if infected necrosis), pain control, ERCP within 24-72 hours if biliary pancreatitis with cholangitis. Drainage of infected necrosis: step-up approach — percutaneous drain first, then minimally invasive necrosectomy if needed (PANTER trial superior to open necrosectomy).

MCQ 5: 62-year-old hypertensive man with sudden severe tearing chest and back pain

Image description: [Axial CT angiogram of the chest at the level of the aortic arch and descending aorta. A linear hypoattenuating intimal flap is visible within the descending thoracic aorta separating two contrast-filled lumens of differing density (the slower-flowing false lumen is slightly less dense). The ascending aorta appears normal calibre 3.6 cm with a single lumen. The descending aorta measures 4.8 cm. Small left pleural effusion. No pericardial effusion. The intimal flap extends from the level of the left subclavian origin to the diaphragm on the available images.]

Clinical vignette: A 62-year-old hypertensive man (poorly compliant with amlodipine) presents with sudden onset of severe tearing interscapular pain that started 90 minutes ago while at rest. He is diaphoretic. BP 196/110 right arm, 178/96 left arm (20 mmHg differential). ECG: sinus tachycardia 108, no ST elevation, mild LVH. Troponin negative. Chest X-ray shows widened mediastinum.

Options:

• (a) Stanford Type A aortic dissection — surgical emergency
• (b) Stanford Type B aortic dissection — medical management
• (c) Pulmonary embolism with right heart strain
• (d) Esophageal rupture (Boerhaave syndrome)

Correct answer: (b) Stanford Type B aortic dissection — medical management

Reasoning: The intimal flap is confined to the descending aorta distal to the left subclavian artery, with normal ascending aorta — by definition Stanford Type B. Stanford classification is the most clinically relevant:

DeBakey: Type I = ascending + arch + descending; Type II = ascending only; Type III = descending only (IIIa above diaphragm, IIIb below).

Teaching pearl: Workflow for suspected aortic dissection in NEET PG:

1. Clinical clue — sudden severe tearing chest/back pain, BP differential between arms >20 mmHg, pulse deficit, new aortic regurgitation murmur (Type A), neurological deficit (Type A with carotid involvement), Marfan or Ehlers-Danlos
2. First imaging — CT angiogram of chest and abdomen (sensitivity 99%, specificity 98%) — gold standard
3. Alternatives — TEE if hemodynamically unstable (cannot leave bedside); MRI if iodine contrast contraindicated
4. Treatment Type A — emergency cardiothoracic surgery (replacement of ascending aorta + valve as needed); IV labetalol or esmolol to target HR <60 and SBP <120
5. Treatment Type B — IV labetalol or esmolol first (HR <60), then add nitroprusside or nicardipine for SBP <120; avoid vasodilator-only therapy (causes reflex tachycardia worsening shear stress); TEVAR if complicated (malperfusion, rupture, persistent pain, expansion)
6. Monitor — pulse, BP every limb, neurological status, urine output, distal pulses
7. Risk factors to remember — chronic hypertension (most common), Marfan, Ehlers-Danlos, bicuspid aortic valve, pregnancy (3rd trimester), cocaine use, trauma, vasculitis

The intimal flap is the diagnostic finding. Ancillary clues on CT: cobweb sign (residual intimal strands in false lumen), beak sign (acute angle of false lumen at intimal flap), false lumen with thrombus, mediastinal hematoma. On chest X-ray (limited sensitivity ~70%): widened mediastinum >8 cm, left apical cap, deviation of trachea, calcium sign (separation of intimal calcium from outer aortic wall by >1 cm).

Common pitfalls in CT abdomen MCQs

Pitfall 1: Missing free air on soft-tissue windows. Always switch to lung windows when perforation is suspected. As little as 1-2 mL of gas is detectable.

Pitfall 2: Calling adhesive SBO when there is no surgical history. Without prior abdominal surgery, look harder for hernia, mass, gallstone ileus, internal hernia, intussusception. "Adhesions" without surgical history is unusual.

Pitfall 3: Confusing fluid collection with abscess in pancreatitis. Gas within a collection is pathognomonic for infection; without gas, only clinical context (fever, leukocytosis) and aspiration distinguish them.

Pitfall 4: Misclassifying Type A vs Type B dissection. The boundary is the left subclavian origin. If the intimal flap extends even 1 cm into the ascending aorta or arch proximal to the left subclavian, it is Type A — surgical emergency.

Pitfall 5: Diagnosing appendicitis without confirming the appendix is dilated. A normal appendix can be seen up to 6 mm; the diagnostic threshold is >6 mm with wall changes. A normal-sized appendix in a patient with RIF pain warrants alternative diagnosis search.

Pitfall 6: Calling pancreatic enlargement "pancreatitis" without context. Adenocarcinoma can mimic focal pancreatitis. Look for ductal dilatation upstream, abrupt cut-off (double duct sign), and clinical/lab data.

Pitfall 7: Treating Stanford Type B with surgery first. Medical BP control is first-line; TEVAR is for complications (malperfusion, rupture, refractory pain, rapid expansion).

Systematic CT abdomen approach (the 8-step search pattern)

Apply this to every NEET PG CT abdomen MCQ:

1. Window check — soft tissue (W350/L40) for parenchyma; lung window (W1500/L-600) for free air; bone window for calcifications
2. Solid organs — liver, spleen, pancreas, kidneys, adrenals: size, enhancement, lesions
3. Hollow organs — stomach, small bowel, colon, appendix: calibre, wall thickness, content, transitions
4. Mesentery and fat — stranding (inflammation), mass, vessels (whirl, beak)
5. Free air, free fluid, free fat — anterior to liver, Morison pouch, pelvic dependent
6. Vascular — aorta calibre, intimal flap, mesenteric vessels, portal vein gas
7. Retroperitoneum — psoas, lymph nodes, IVC, ureters
8. Bones and lung bases — incidental fractures, lung consolidation

How NEET PG tests CT abdomen

NEET PG tests CT abdomen through six dominant patterns:

• Pattern 1 — Image identification: name the diagnosis (appendicitis, perforation, SBO, pancreatitis, dissection)
• Pattern 2 — Severity grading: Balthazar / MCTSI for pancreatitis; Stanford for dissection
• Pattern 3 — Etiological clues: transition point in SBO, gallstone in Rigler triad
• Pattern 4 — Modality selection: CT vs USG vs MRI for the clinical question
• Pattern 5 — Complication recognition: abscess, infected necrosis, strangulation, rupture
• Pattern 6 — Management linkage: image findings drive medical vs surgical decision

High-yield one-liners for last-day revision:

• Appendix >6 mm + fat stranding = appendicitis
• Free air on lung window = perforation = laparotomy
• SBO transition point + post-op = adhesions
• Closed-loop SBO = surgical emergency (whirl sign of mesenteric vessels)
• Rigler triad = pneumobilia + SBO + ectopic gallstone = gallstone ileus
• Best CT timing in pancreatitis = 72-96 hours
• Balthazar A-E; MCTSI 0-10; severe = 8-10
• Gas in necrotic collection = infected necrosis
• Stanford A = ascending aorta = surgery; Stanford B = descending = medical
• BP differential >20 mmHg + tearing pain = dissection until proven otherwise

Frequently Asked Questions

What CT findings confirm acute appendicitis?

Six findings, any combination supports the diagnosis: dilated appendix more than 6 mm in transverse diameter, wall thickening more than 2 mm with mural enhancement, periappendiceal fat stranding, appendicolith (visible in 30-40 percent), focal cecal apical thickening (arrowhead sign), and periappendiceal fluid or phlegmon. Complicated appendicitis is suggested by abscess, free air (perforation), or extraluminal appendicolith. Sensitivity of CT is 95-98 percent and specificity 95 percent — the gold standard for adult evaluation; USG is preferred in children and pregnancy.

How do you identify free air on abdominal CT?

Free intraperitoneal air is best seen on lung-window settings on CT. Look for: gas anterior to the liver (subdiaphragmatic free air on coronal reformats), gas in the falciform ligament outlining its course, gas pockets between bowel loops (interloop air), Rigler sign (air outlining both sides of the bowel wall), gas in the lesser sac, and air tracking along the diaphragm. As little as 1-2 mL of free gas is visible on CT compared to 50 mL needed for upright chest X-ray. Free air with peritonitis = emergency laparotomy.

How do you find the transition point in small bowel obstruction on CT?

Trace the dilated small bowel loops (more than 2.5 cm proximal to obstruction) downstream until they meet collapsed bowel — the transition point is the abrupt calibre change. Causes by proximity: adhesions (most common in post-surgical patients, no mass at transition point), hernia (defect in abdominal wall), tumour (mass at transition), gallstone ileus (Rigler triad — pneumobilia, SBO, ectopic gallstone), intussusception (target sign), volvulus (whirl sign of mesenteric vessels). Closed-loop obstruction (two transition points close together with C-shaped or U-shaped distended loop) is a surgical emergency.

What is the Balthazar / Modified CT Severity Index for acute pancreatitis?

Balthazar grades A-E: A normal pancreas, B focal/diffuse enlargement, C peripancreatic inflammation, D single peripancreatic fluid collection, E two or more fluid collections or retroperitoneal gas. Modified CT Severity Index (MCTSI, max 10) combines: pancreatic inflammation (0/2/4 points for grades A/B-C/D-E), pancreatic necrosis (0/2/4/6 points for none, less than 30, 30-50, more than 50 percent), and extrapancreatic complications (0/2 points). MCTSI 0-2 mild, 4-6 moderate, 8-10 severe (mortality 50-70 percent). Best timing: 72-96 hours after onset for accurate necrosis assessment.

How is aortic dissection diagnosed on CT angiography?

CT aortogram is the gold standard. Diagnostic finding: an intimal flap separating two contrast-filled lumens — true and false. Stanford classification: Type A involves the ascending aorta (surgical emergency, mortality 1-2 percent per hour untreated); Type B is descending only (medical management with BP control unless complicated). Look for ascending aorta diameter more than 4 cm, mediastinal widening on chest X-ray as a screening clue, branch vessel involvement (coronaries, arch vessels, renals), pericardial effusion (suggests rupture in Type A). Avoid IV contrast only if eGFR less than 30 — in this emergency, the diagnostic benefit usually outweighs renal risk.

---

Written by: NEETPGAI Editorial Team Reviewed by: Pending SME Review Last reviewed: April 2026
